Subtype: Cushion Tire 4 Wheel Sit Down (Indoor Warehouse)
Fuel Type: LP Gas
General Dimensions:
Overall Length: 138.2 inches
Overall Width: 46.5 inches
Height to Top Overhead Guard: 86.6 inches
Turning Radius: 93.3 inches
Performance:
Load Capacity: 8,000 lbs
Engine Power: 97 HP
Travel Speed (Loaded): 11.3 mph
Travel Speed (Unloaded): 12.1 mph
Lift Speed (Loaded): 93 ft/min
Lift Speed (Unloaded): 106 ft/min
Lowering Speed (Loaded): 98 ft/min
Lowering Speed (Unloaded): 95 ft/min
Chassis:
Tire Type: Cushion
Number of Wheels: 4
Wheelbase: 65.0 inches
Ground Clearance (Center of Wheelbase): 4.0 inches
Powertrain:
Engine Type: Internal Combustion, LPG
Engine Manufacturer: GM 4.3L V6
Transmission Type: Powershift
Number of Speeds: 2 Forward / 1 Reverse
Hydraulic System:
Hydraulic Pump Type: Gear Type
Hydraulic Flow Rate: 19.8 gal/min
Operator Environment:
Seating: Ergonomic Design with Adjustable Seat
Steering: Hydrostatic Power Steering
Noise Level: 79 dB(A)
Additional Equipment:
Lights: LED Headlights and Tail Lights
Safety Features: Presence Detection System
Display: Multifunctional LCD Display
CALL FOR RENTAL RATES
Reserve Rental
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
Motor Service, Inc. Sales Dept.: 314 200 0520 130 Byassee Dr Hazelwood, MO 63042
Subtype: Cushion Tire 4 Wheel Sit Down (Indoor Warehouse)
Fuel Type Used: LP Gas
Dimensions:
Overall Length: 145 inches (varies depending on fork length)
Overall Width: 46 inches
Overall Height (Overhead Guard): 87 inches
Wheelbase: 78 inches
Capacity:
Load Capacity: 10,000 lbs
Load Center: 24 inches
Engine:
Type: Internal Combustion
Fuel: LP Gas
Performance:
Travel Speed (Full Load): 12 mph
Lifting Speed (Full Load): 100 feet/min
Tires:
Type: Cushion
Tire Size (Front): 21x7x15 inches
Tire Size (Rear): 16x6x10.5 inches
CALL FOR RENTAL RATES
Reserve Rental
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
Motor Service, Inc. Sales Dept.: 314 200 0520 130 Byassee Dr Hazelwood, MO 63042
