In the material handling industry, a paper clamp is a specialized forklift attachment designed for efficient and damage-free handling of various types of paper products, such as rolls, bales, or stacks of sheet paper. These clamps eliminate the need for pallets by securely gripping the load from the sides, allowing for precise lifting, transporting, and stacking. Equipped with rubberized pads or surfaces to enhance grip and minimize the risk of damage, paper clamps are commonly used in printing facilities, paper mills, and distribution centers where the safe and efficient movement of paper products is essential. Their design typically allows for rotation and tilt to accommodate different operational needs, contributing to enhanced productivity and safety in material handling processes.
TISSUE ROLL PAPER ROLL CLAMP - SWING FRAME
RENTAL ONLY
Manufacturer: Cascade
Model Number: 90F-SCP-SP
Type: Attachment
Subtype: Paper Roll Clamps
Specifications
Capacity: 9,000 lbs
Clamp Type: Short Arm Type
Performance
Rotation: 360 degrees continuous
Opening Range: 19.7" to 61" (50 cm to 155 cm)
Recommended Operating Pressure: 2,300 psi
Frame and Construction
Material: High strength steel
Arm Thickness: 2.8" (7 cm)
Hydraulics
Number of Hydraulic Functions: Two
Hydraulic Flow Range: 18-22 GPM
Weight and Dimensions
Weight: 3,100 lbs
Width: 66" (168 cm)
Height: 52" (132 cm)
Depth: 28" (71 cm)
MONTHLY RENTAL
$930 USD
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
Recommended Forklift Class: Class II and Class III
Features
Hydraulic Function: 2 required
Quick-attach system for easy installation
Heavy-duty construction for durability
MONTHLY RENTAL
$1 USD
WEEKLY RENTAL
$1 USD
DAILY RENTAL
$1 USD
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
**General Specifications**
- Model Number: 30H-RCP-B001
- Manufacturer: Cascade
- Type: Attachment
- Subtype: Paper Roll Clamps
**Dimensions**
- Arm Length: varies
- Frame Width: approximately 40 inches
- Clamp Opening Range: approximately 10 to 60 inches
**Capacity**
- Load Capacity: 6,000 lbs
**Performance**
- Rotation: 360 degrees continuous
- Clamping Force: adjustable
- Cycle Speed: approximately 8 seconds for full rotation
**Hydraulic Requirements**
- Operating Pressure: 2,000 - 2,500 PSI
- Flow Rate: 10 - 15 GPM
**Material & Construction**
- Material: High-strength steel
- Finish: Powder-coated
**Weight**
- Attachment Weight: approximately 1,500 lbs
**Additional Features**
- Valve Options: Available for different flow rates
- Pads: Rubber-coated for minimal roll damage
- Mounting Class: Class II or III depending on configuration
- Control Options: Manual or hydraulic controls available
MONTHLY RENTAL
$1 USD
WEEKLY RENTAL
$1 USD
DAILY RENTAL
$1 USD
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
Clamp Opening Range: Approximately 2 inches to 67 inches
Arm Length: Varies
Frame Width: Approximately 47 inches
Weight: Approximately 1,500 lbs
Maximum Roll Diameter: Up to 67 inches
Minimum Roll Diameter: Approximately 2 inches
Performance:
Load Capacity: 5,500 lbs
Optimal Operating Pressure: 2,000 psi
Hydraulic Flow: Minimum 7 gal/min
Features:
Side shifting function for better maneuverability
Non-marking rubber pads to protect paper rolls
360-degree rotation capability
Durable construction for heavy-duty use
Compatible with various forklift models
Operational Requirements:
Requires hydraulic system
Mounting Class: Varies based on specific forklift configuration
MONTHLY RENTAL
$1 USD
WEEKLY RENTAL
$1 USD
DAILY RENTAL
$1 USD
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
Specially designed contact pads to ensure secure grip
Rotation:
360-degree continuous rotation capability
Mounting Interface:
Standard mounting options for easy installation
Hydraulics:
Equipped with hydraulic valves and hoses for control
Pressure requirements based on application
Weight:
Heavy-duty construction for durability
Applications:
Specifically designed for handling paper rolls
Adjustable Features:
Adjustable arms for accommodating various roll sizes
Compatibility:
Compatible with a wide range of lift trucks
MONTHLY RENTAL
$1 USD
WEEKLY RENTAL
$1 USD
DAILY RENTAL
$1 USD
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
Clamp Opening Range: Approximately 8 inches to 96 inches
Weight: Approximately 1,500 lbs
Capacity
Maximum Load Capacity: Up to 5,000 lbs
Performance
Rotation: 360 degrees
Power Source: Hydraulic
Materials
Clamp Pads: Durable, non-marking rubber
Compatibility
Suitable for handling various paper roll diameters
Adaptable with most forklift models
Additional Features
Adjustable Pressure Control for safe handling
Highly visible decal for operation guidelines
Optimized for minimal product damage
MONTHLY RENTAL
$1 USD
WEEKLY RENTAL
$1 USD
DAILY RENTAL
$1 USD
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
ATTACHCO Andrew Forde 665 W Cowles St Long Beach , CA 90813
**Specifications of Model 77F-RCP Paper Roll Clamp**
**General Information**
- **Manufacturer:** Cascade
- **Model Number:** 77F-RCP
- **Type:** Attachment
- **Subtype:** Paper Roll Clamps
**Performance**
- **Capacity:** Varies with model specifications
- **Rotation:** 360 degrees continuous
- **Opening Range:** Varies according to needs
- **Clamp Force:** Adjustable to accommodate paper types
- **Roll Diameter Capacity:** Varies, designed for different roll sizes
- **Horizontal and Vertical Speed:** Suitable for operational needs
**Dimensions**
- **Arm Height:** Varies based on configuration
- **Thickness:** Designed for roll stability and strength
- **Length:** Varies based on requirements
- **Width:** Proportional to arm size for balance
**Weights**
- **Attachment Weight:** Varies depending on configuration
- **Load Center:** Standard based on industry practices
**Hydraulic Specifications**
- **Pressure Requirement:** Typically ranges in normal operational psi
- **Hydraulic Flow:** Adjustable to accommodate different operations
**Additional Features**
- **Endurance:** Built for heavy-duty use and longevity
- **Material Construction:** Made from high-strength steel for durability
- **Ease of Use:** Designed for efficient loading and unloading
- **Safety Features:** Adjustable clamps to prevent roll damage
- **Versatility:** Suitable for various roll types and sizes
**Installation**
- **Mounting Options:** Available for different forklift configurations
- **Compatibility:** Designed to fit with multiple forklift brands and models
Mid Atlantic Industrial Equipment LTD. Sales Dept. 1231 E Wallace St York, PA 17403
FINANCING
All finance rates, terms, and conditions are subject to approval and may change without prior notice. Rates are provided for informational purposes only and are not guaranteed. Final rates and terms will depend on creditworthiness, market conditions, and other factors at the time of application.
Notes: Quote is valid for 7 days. Quotes are subject to credit approval and applicable taxes are not included. Any lead times are factory estimates and are not guaranteed. Units canceled by customer after 24 hours of placing order will be charged a 25% fee. Mid Atlantic reserves the option to add any surcharges/increases beyond its control OR cancel the order in which case the customer will not be charged any fee. Finance/lease rates are subject to change after 90 days on ordered equipment pending arrival. Inbound freight is estimated at time of quote but subject to the rate at time of shipping on ordered units.
Payment Terms: Purchased equipment is due net upon delivery. Credit card payments will incur a 3.5% fee.
Financed/Leased Equipment: Documentation must be completed and signed upon or before delivery. Equipment cannot be placed in service until finance and warranty documents are executed.
**Specifications for Cascade RC2G-5242 Paper Roll Clamps**
**General Information**
- **Model Number:** RC2G-5242
- **Manufacturer:** Cascade
- **Type:** Attachment
- **Subtype:** Paper Roll Clamps
**Capacity**
- **Load Capacity:** Information needed for exact capacity
- **Clamp Force:** Variable, adjust according to roll weight and size
**Dimensions**
- **Roll Diameter Range:** Approx. 17.3 inches to 60 inches
- **Frame Width:** Approximately 59 inches
- **Opening Range:** Approximately 20 inches to 64 inches
**Weight**
- **Attachment Weight:** Varies based on configuration
**Construction**
- **Build Material:** High-strength steel
- **Finish:** Powder-coated for durability and corrosion resistance
**Performance**
- **Maximum Clamp Force:** Variable, hydraulic pressure adjustable for performance tuning
- **Rotation:** 360 degrees continuous rotation
**Hydraulic Requirements**
- **Number of Hydraulic Functions:** 2 (clamping and rotation)
- **Hydraulic Pressure Range:** 1500 to 2300 psi
**Additional Features**
- **Arm Design:** Heavy-duty arms for handling various roll types
- **Clamping Surface:** Designed to maximize grip while minimizing roll damage
- **Mounting:** Quick-attach compatibility for fast installation and removal
**Operating Conditions**
- **Temperature Range:** Operational in diverse temperatures from -20°F to 120°F
**Compatibility**
- **Forklift Compatibility:** Check compatibility with forklift model for optimal operation
**Maintenance**
- **Service Interval:** Periodic inspection recommended every 200 hours of operation
**Safety**
- **Integrated Safety Features:** Pressure relief valve to prevent over-clamping
- **Operator Visibility:** Designed for optimal visibility during operation
