Spec Sheet
  • Model Details
    • Model Number: Z-34/22 DC
    • Manufacturer: Genie
    • Type: Boom Lift
    • Subtype: Articulated Boom
  • Performance
    • Power Source: Electric
    • Platform Capacity: 500 lbs
    • Horizontal Reach: 22 ft 3 in
    • Up and Over Clearance: 15 ft 2 in
    • Gradeability: 30%
    • Drive Speed - Stowed: 4.0 mph
    • Drive Speed - Raised: 0.68 mph
  • Dimensions
    • Platform Height: 34 ft
    • Platform Length: 2 ft 6 in
    • Platform Width: 4 ft 8 in
    • Width: 4 ft 11 in
    • Height - Stowed: 6 ft 6 in
    • Length - Stowed: 18 ft 1 in
    • Wheelbase: 6 ft 1 in
    • Ground Clearance: 5.5 in
  • Weights
    • Machine Weight: 11,050 lbs
  • Features
    • Proportional controls
    • Hydraulic rotating platform
    • AC power cord to platform
    • Motion alarm
    • Hour meter
    • Tilt alarm
Legal Disclaimer

The specifications provided herein are for informational purposes only and are not guaranteed to be 100% accurate. This tool is currently in beta testing, and while we strive to provide the most accurate and up-to-date information, there may be discrepancies or errors. We strongly recommend that you verify all specifications and details with the manufacturer of the equipment or an authorized dealer. The information presented should not be considered definitive or relied upon as the sole basis for decision-making. In some cases, certain specifications are based on new equipment when shipped from the factory and may have changed over time. For example, masts and forks are routinely changed or updated. Headlights, taillights, and backup alarms are usually included with new equipment, but can be removed over time. Neither the creators of this tool nor any affiliated parties shall be held liable for any inaccuracies, errors, or omissions in the information provided. By using this tool, you acknowledge and agree that you assume all risks associated with the use of the specifications and information provided. For 100% accuracy and the most reliable information, please contact the manufacturer of the equipment or an authorized dealer directly.

2018 Genie Z-34/22 DC

articulated boom electric

$26,900 USD

Instant Quote Eligible Listing - CLICK HERE!
CONTACT INFO
Name:
Equipment Sales
Phone:

ADDRESS
Elite Material Handling - Grapevine
900 Port America Place
GrapevineTexas 76051
ATTRIBUTES
STOCK #:
GN127
YEAR:
2018
Manufacturer:
MODEL #:
SUBCATEGORY:
Height:
34 ft
FUEL:
SERIAL #:
Z34F-12860
CONDITION:
Used
HOUR METER:
236
LOCATION:
POST DATE:
12/1/2025
Reviews
Useful
Not

The Genie Z-34/22 DC articulating boom lift really impressed me during a recent project where I was tasked with some outdoor maintenance work. It was great to see how smoothly the electric operation allowed for quiet use near residential areas without disturbing anyone, which was a definite plus. I found the maneuverability particularly handy for accessing those tricky spots in my backyard, like near the tall trees that always seemed just out of reach. After a few hours of working with it, I appreciated how comfortable the platform felt, making it easy to focus on the task rather than balancing or feeling uneasy. Overall, this boom lift helped me get the job done efficiently and safely.
