Genie Boom Lifts are known for their innovation and versatility in the aerial lift market. One feature that sets them apart is their extensive range of models designed for various applications, including electric, hybrid, and engine-powered options. Genie Boom Lifts are engineered for both outdoor and indoor use, offering significant outreach and height capabilities. They often come equipped with advanced safety features and easy-to-use controls, enhancing operator confidence and efficiency. Additionally, Genie emphasizes maneuverability and reliability, with models designed to navigate tight spaces and challenging terrains. Their commitment to incorporating cutting-edge technology for improved performance and sustainability also differentiates them in the industry.
Engine: Dual fuel engine capable of using both gasoline and propane
Fuel Capacity: Approximately 20 gallons (gasoline)
Hydraulic System
Hydraulic Tank Capacity: Approximately 8 gallons
Brakes
Service Brakes: Hydraulic, wet disc brakes on front axle
Steering
Type: Hydraulic power steering
Steering Angle: 50°
Wheels
Tire Type: Pneumatic
Number of Wheels: 4
CALL FOR RENTAL RATES
Reserve Rental
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
Motor Service, Inc. Sales Dept.: 314 200 0520 130 Byassee Dr Hazelwood, MO 63042
Call for sale pricing or rental rates! 314-731-4111
Model Number: Z-45/25J
Manufacturer: Genie
Type: Boom Lift
Subtype: Articulated Boom
Fuel Type: Gasoline
Dimensions:
Height Stowed: Approximately 6.6 ft
Length Stowed: Approximately 18 ft
Width: Approximately 7.5 ft
Performance:
Horizontal Reach Maximum: Approximately 25 ft
Up and Over Clearance Maximum: Approximately 20 ft
Gradeability: Around 30%
Lift Capacity: Approximately 500 lbs
Turning Radius (Inside): Approximately 6.8 ft
Turning Radius (Outside): Approximately 14.2 ft
Travel Speed: Approximately 3.5 mph
Power:
Engine: Gasoline
Engine Power: Approximately 24 hp
Fuel Tank Capacity: Approximately 15 gallons
Weight:
Total Weight: Approximately 14,900 lbs
Functionality:
Platform Rotation: 180 degrees
Jib Range of Motion: 135 degrees
CALL FOR RENTAL RATES
Reserve Rental
All rental rates are subject to change without prior notice. Pricing may vary based on availability, demand, seasonal factors, or updates to policies. Rates provided at the time of inquiry or reservation are not guaranteed until confirmed. The rental provider reserves the right to adjust rates at their discretion.
Motor Service, Inc. Sales Dept.: 314 200 0520 130 Byassee Dr Hazelwood, MO 63042
Call for sale pricing or rental rates! 314-731-4111
General Specifications
Model Number: S-85
Manufacturer: Genie
Equipment Type: Boom Lift
Subtype: Telescopic Boom
Dimensions
Overall Length: 37 ft 3 in
Overall Width: 8 ft 2 in
Height (stowed): 10 ft 1 in
Wheelbase: 9 ft
Ground Clearance: 1 ft
Platform Length: varies
Platform Width: varies
Performance
Horizontal Reach: 72 ft 6 in
Lift Capacity: 500 lbs
Turning Radius (outside): 19 ft 4 in
Drive Speed: 3.4 mph
Gradeability: 34%
Power
Engine: Deutz Diesel
Power Output: 74 hp
Fuel Tank Capacity: 40 gallons
Hydraulic Tank Capacity: 28 gallons
Operational
Platform Rotation: 160 degrees
Turntable Rotation: 360 degrees continuous
Axle Configuration: 4x4
Tires: Foam-filled
Safety Features
Load Sensing System
Tilt Alarm with Drive & Lift Cut-Out
Platform Entry Toeboards
Emergency Stop at Platform and Ground Controls
Weights
Machine Weight: 39,200 lbs
