Equipment Description
Genie Z-60 FE – Hybrid Aerial Boom Lift • Working Height: 65’7”, Horizontal Reach: 36’7” • Dual-mode operation: Hybrid (diesel) or Battery-Electric • Rugged 4WD, rough-terrain capable, articulating jib, and smooth proportional controls • All-terrain powerhouse built for precision lifts and clean performance Call us today at 866-764-5438 to secure this advanced, eco-friendly lift for your fleet!
Spec Sheet
Legal Disclaimer

The specifications provided herein are for informational purposes only and are not guaranteed to be 100% accurate. This tool is currently in beta testing, and while we strive to provide the most accurate and up-to-date information, there may be discrepancies or errors. We strongly recommend that you verify all specifications and details with the manufacturer of the equipment or an authorized dealer. The information presented should not be considered definitive or relied upon as the sole basis for decision-making. In some cases, certain specifications are based on new equipment when shipped from the factory and may have changed over time. For example, masts and forks are routinely changed or updated. Headlights, taillights, and backup alarms are usually included with new equipment, but can be removed over time. Neither the creators of this tool nor any affiliated parties shall be held liable for any inaccuracies, errors, or omissions in the information provided. By using this tool, you acknowledge and agree that you assume all risks associated with the use of the specifications and information provided. For 100% accuracy and the most reliable information, please contact the manufacturer of the equipment or an authorized dealer directly.

  • Manufacturer: Genie
  • Model Number: Z-60 FE
  • Type: Boom Lift
  • Subtype: Articulated Boom
  • Fuel Type: Bi-Energy (Electric and Diesel)
  • Dimensions
    • Width: Approximately 8 ft
    • Height (Stowed): Approximately 8 ft 2 in
    • Length (Stowed): Approximately 25 ft 3 in
    • Ground Clearance: Approximately 1 ft
    • Platform Size: 7 ft 5 in x 2 ft 6 in
  • Performance
    • Horizontal Reach: Approximately 36 ft 7 in
    • Lifting Capacity: 500 lbs
    • Platform Rotation: 160 degrees
    • Jib Horizontal Rotation: 180 degrees
    • Turntable Rotation: 355 degrees non-continuous
    • Drive Speed: 4 mph
    • Gradeability: 45%
  • Power
    • Power Source: Hybrid (Diesel engine and battery)
    • Diesel Engine: 24.8 hp
    • Battery: 48V DC
    • On-board Generator: 75 amps
  • Weight
    • Total Weight: Approximately 17,100 lbs
  • Features
    • AC Power to Platform
    • Foam-filled Tires
    • Hybrid System with Regenerative Braking
    • Full-time Active Oscillating Axle

Genie Z-60 FE

New

articulated boom

Call for price

CONTACT INFO
Name:
Sales Dept.
Phone:

ADDRESS
Supreme Forklift & Equipment
25250 S Power Rd
Queen CreekArizona 85142
ATTRIBUTES
Manufacturer:
MODEL #:
Drive:
4WD
SUBCATEGORY:
Height:
60 ft
CONDITION:
New
HOUR METER:
1
UNIT LOCATION:
Arizona [85142]
DESCRIPTION:
CALL FOR CURRENT PRICING
POST DATE:
3/2/2026
Reviews
Useful
Not

The Genie Z-60 FE boom lift is a real game-changer for anyone needing to access high spots without breaking a sweat. I remember one project where I had to paint the upper eaves of my house, and this lift made the task not only easier but surprisingly enjoyable. It maneuvered pretty well, even in tighter spaces, and the controls felt intuitive. The stability gave me the confidence to really reach out and tackle some tough angles. For someone who's no stranger to a little DIY, having a reliable lift like this on hand feels like leveling up your toolkit. Definitely worth considering if you're in the market!


Review by John Thompson (3/16/2025)

  • Manufacturer: Genie
  • Model Number: Z-60 FE
  • Type: Boom Lift
  • Subtype: Articulated Boom
  • Fuel Type: Bi-Energy (Electric and Diesel)
  • Dimensions
    • Width: Approximately 8 ft
    • Height (Stowed): Approximately 8 ft 2 in
    • Length (Stowed): Approximately 25 ft 3 in
    • Ground Clearance: Approximately 1 ft
    • Platform Size: 7 ft 5 in x 2 ft 6 in
  • Performance
    • Horizontal Reach: Approximately 36 ft 7 in
    • Lifting Capacity: 500 lbs
    • Platform Rotation: 160 degrees
    • Jib Horizontal Rotation: 180 degrees
    • Turntable Rotation: 355 degrees non-continuous
    • Drive Speed: 4 mph
    • Gradeability: 45%
  • Power
    • Power Source: Hybrid (Diesel engine and battery)
    • Diesel Engine: 24.8 hp
    • Battery: 48V DC
    • On-board Generator: 75 amps
  • Weight
    • Total Weight: Approximately 17,100 lbs
  • Features
    • AC Power to Platform
    • Foam-filled Tires
    • Hybrid System with Regenerative Braking
    • Full-time Active Oscillating Axle
