Equipment Description
Arm Height 48" Arm Length 48" Arm Thickness 2.13" at Pivot Capacity 3500 lbs @ 24 inch Load Center Estimated Weight 1500 lbs Flow Divider Yes Frame Width 41" Horizontal Center of Gravity 15.3" Hook Spread 29" Lateral Center of Gravity 10.4" at maximum shift Lost Load 5.88" Lower Hook Bolt On Maximum Flow 20 gpm Maximum Pressure 2400 psi Maximum Offset 14.03" Minimum Flow 12 gpm Mounting Class Class II Opening Range 21.38" - 77.5" Recommended Flow 16 gpm Recommended Pressure 2250 psi Sideshift Yes Vertical Center of Gravity 12.6"
Spec Sheet
Legal Disclaimer

The specifications provided herein are for informational purposes only and are not guaranteed to be 100% accurate. This tool is currently in beta testing, and while we strive to provide the most accurate and up-to-date information, there may be discrepancies or errors. We strongly recommend that you verify all specifications and details with the manufacturer of the equipment or an authorized dealer. The information presented should not be considered definitive or relied upon as the sole basis for decision-making. In some cases, certain specifications are based on new equipment when shipped from the factory and may have changed over time. For example, masts and forks are routinely changed or updated. Headlights, taillights, and backup alarms are usually included with new equipment, but can be removed over time. Neither the creators of this tool nor any affiliated parties shall be held liable for any inaccuracies, errors, or omissions in the information provided. By using this tool, you acknowledge and agree that you assume all risks associated with the use of the specifications and information provided. For 100% accuracy and the most reliable information, please contact the manufacturer of the equipment or an authorized dealer directly.

  • General Specifications
    • Manufactured by: Rightline
    • Model Number: LC35H-10-3AC-A
    • Type: Attachment
    • Subtype: Carton Clamps
  • Dimensions
    • Width: 35 inches
    • Height: 30 inches
    • Depth: 12 inches
  • Performance
    • Load Capacity: 2,000 to 3,000 lbs
    • Opening Range: 26 to 56 inches
    • Optimal Pressure Range: 870 to 2,320 psi
  • Construction
    • Material: High-tensile steel
    • Finish: Powder-coated
  • Operational Features
    • Hydraulic System Compatibility: 3 AC
    • Control Options: Manual or Remote
  • Additional Features
    • Damage Prevention Pads: Included
    • Alignment Guides: Adjustable

2018 Rightline LC35H-10-3AC-A

carton clamps

$13,500 USD

Instant Quote Eligible Listing - CLICK HERE!
CONTACT INFO
Name:
Andrew Forde
Phone:
Website:

ADDRESS
ATTACHCO
665 W Cowles St
Long Beach California 90813
ATTRIBUTES
STOCK #:
CC-352
YEAR:
2018
Manufacturer:
MODEL #:
CAPACITY:
3500
CLASS:
II
SUBCATEGORY:
SERIAL #:
194234
CONDITION:
Used
UNIT LOCATION:
California [90813]
DESCRIPTION:
Class 2/3 Convertible Fully Reconditioned 120 Day Warranty
POST DATE:
5/20/2026
  • General Specifications
    • Manufactured by: Rightline
    • Model Number: LC35H-10-3AC-A
    • Type: Attachment
    • Subtype: Carton Clamps
  • Dimensions
    • Width: 35 inches
    • Height: 30 inches
    • Depth: 12 inches
  • Performance
    • Load Capacity: 2,000 to 3,000 lbs
    • Opening Range: 26 to 56 inches
    • Optimal Pressure Range: 870 to 2,320 psi
  • Construction
    • Material: High-tensile steel
    • Finish: Powder-coated
  • Operational Features
    • Hydraulic System Compatibility: 3 AC
    • Control Options: Manual or Remote
  • Additional Features
    • Damage Prevention Pads: Included
    • Alignment Guides: Adjustable
