Big Joe PDM-30-130

electric walkie straddle stacker

Call for price
US Lift & Warehouse Equipment
CONTACT INFO
Name:
Kelly
Phone:

ADDRESS
US Lift & Warehouse Equipment
PO Box 91976
Elk Grove VillageIllinois 60009
ATTRIBUTES
STOCK #:
18010
Manufacturer:
MODEL #:
CAPACITY:
3000
FUEL:
Electric
CONDITION:
Used
LOCATION:
Illinois [60009]
POST DATE:
2/20/2025
Equipment Description
  • General Specifications
    • Model Number: PDM-30-130
    • Manufacturer: Big Joe
    • Type: Forklift
    • Subtype: Electric Walkie Straddle Stacker
    • Fuel Type Used: Electric
  • Dimensions
    • Total Lift Height: 130 inches
    • Overall Length: 77 inches
    • Overall Width: 54.75 inches
    • Fork Length: Varies
    • Wheelbase: 47.25 inches
    • Ground Clearance: 1.25 inches
    • Turning Radius: 60.5 inches
  • Performance
    • Load Capacity: 3,000 lbs
    • Travel Speed Loaded: 2.5 mph
    • Travel Speed Unloaded: 3 mph
    • Drive Motor: 24 V
    • Lift Motor: 2.5 hp
  • Wheels
    • Wheel Type: Polyurethane
    • Number of Wheels: 4
    • Steer Wheel Size: 10 inches
    • Load Wheel Size: 4 inches
  • Battery Details
    • Battery Voltage: 24V
    • Battery Capacity: 250 Ah
    • Battery Weight: 570 lbs
Legal Disclaimer

The specifications provided herein are for informational purposes only and are not guaranteed to be 100% accurate. This tool is currently in beta testing, and while we strive to provide the most accurate and up-to-date information, there may be discrepancies or errors. We strongly recommend that you verify all specifications and details with the manufacturer of the equipment or an authorized dealer. The information presented should not be considered definitive or relied upon as the sole basis for decision-making. In some cases, certain specifications are based on new equipment when shipped from the factory and may have changed over time. For example, masts and forks are routinely changed or updated. Headlights, taillights, and backup alarms are usually included with new equipment, but can be removed over time. Neither the creators of this tool nor any affiliated parties shall be held liable for any inaccuracies, errors, or omissions in the information provided. By using this tool, you acknowledge and agree that you assume all risks associated with the use of the specifications and information provided. For 100% accuracy and the most reliable information, please contact the manufacturer of the equipment or an authorized dealer directly.
