The LiuGong CLG2025G is a Class IV internal combustion forklift delivering 5,000 lbs (2,500 kg) capacity at a 24-inch (500 mm) load center, powered exclusively by a Kubota WJ2503-L-E3 2.491L 4-cylinder LPG engine producing 55.3 HP at 2,600 RPM and 175 N·m of torque at 1,200 RPM, with EU Stage V and EPA emissions compliance for clean indoor operation. This unit is equipped with a 3-stage mast offering a maximum fork height of 185 inches (4,700 mm) with 46 inches (1,170 mm) of free lift, lowering to 87.2 inches (2,215 mm) and extending to 227.3 inches (5,774 mm), with 6 degrees forward and 12 degrees backward mast tilt, and features a 40.9-inch carriage, 42.1 x 3.9 x 1.6 inch forks with a minimum spread of 9 inches and maximum of 39.8 inches, and comes standard with a side shifter for improved load positioning. The forklift rides on pneumatic tires (front: 7.0-12-12PR, rear: 6.00-9-10PR) on a 65-inch wheelbase with a front tread of 37.8 inches and rear tread of 39 inches, delivering an 89.8-inch minimum outside turning radius and a right-angle stack of 158.1 inches including load length and clearance, with travel speeds of 10 mph loaded and 10.6 mph unloaded, lift speeds of 134 fpm loaded and 140 fpm unloaded, lower speeds of 102 fpm loaded and 94 fpm unloaded, maximum drawbar pull of 4,180 lbs loaded, and gradeability of 20% loaded and 30% unloaded. Weighing 8,844 lbs unloaded with axle loads of 11,490 lbs front and 2,851 lbs rear when loaded and 2,741 lbs front and 6,100 lbs rear when unloaded, the chassis measures 100 inches to fork face, 45.3 inches overall width, and 85.8 inches overhead guard height, with ground clearance of 3.5 inches below the mast loaded and 5.7 inches at the center of the wheelbase, while service brakes are foot-operated hydraulic and parking brake is hand-operated mechanical. Optional equipment can include non-marking tires, foam-filled tires, 72-inch forks, enclosed cabs, fork positioners, rotators, clamps, and 3-way or 4-way hydraulic valve configurations to match your specific material handling needs. Contact us today for more details, pricing, or to schedule an inspection.
